DescriptionAn extensive series of ignition switches that can also be usedas rotary switches. Suitable for a broad range of voltages:20A at 12V, 10A at 24V, 6A at 36V and 4A at 48V DC. Made ofrugged engineering grade plastic, these switches stand up tomechanical shock and vibration, and will not corrode or rust.This switch has an integrated Deutsch-type socket to makeelectrical connection quick and easy, and to exclude moistureand dust.Many options available with regard to position, springreturn, key boot style and marking, actuator interface andlength, and anti-restart features.

Specifications

Contact Ratings:

20A @ 12V DC

10A @ 24V DC

6A @ 36V DC

4A @ 48V DC

Electrical life:50,000 cycles

Hardware: Plastic facenut and nickel-platedbrass backing nut

Mounting Torque: Plastic facenut: 7.376-8.85 ft-lbs(10-12 Nm)

Features and Benefits

? Engineering thermoplastic construction

? Fully sealed contact area using O-rings andultrasonic welding

? Integrated Sealed Deutsch Connector Interface

? Anti-restart and spring return options available

? Supplied with two matching keys, with or without boot

? Custom logo can be molded on the boot

? Multiple key codes or keyed alike available

? Key is removable only at the ‘Off’ position
